Product Description

We are an unparalleled name, engaged in supplying a wide assortment of Laser Wavelength Meter. This meter is efficiently manufactured by utilizing superior grade components with the help of latest techniques in conformity with set industry quality standards at our reliable vendors end. Examined on varied quality parameters by our experts, offered meter is mainly used for measuring the wave length of the laser beams. Furthermore, we provide this Laser Wavelength Meter in diverse specifications and at industry leading prices.

Features:

Long operational life
Impeccable performance
High functionality
Sturdiness

HighFinesse-Angstrom Wavelength Meters

High Finesse/Angstrom offers sensitive and compact wavelength meters with a large spectral range for high speed measurement of lasers. The optical unit consists of temperature-controlled interferometers that are read out by photodiode arrays. The high absolute accuracy is achieved by use of solid state, non-moving optics.

Blank

WS5 Precision		3000 MHz
WS6 High Precision		600 MHz
WS7 Super Precision		60 MHz
WSU Ultimate Precision	Unrivaled accuracy up to	2 MHz
Measured at 1064, 780, 532 and 390 nm

Standard	350 1120nm
UV	248 1100nm
UV-II	192 800nm
IR	630 1750nm
IR-II	1000 2250nm
ultra sensitive	<10 500nm
high-speed measurement	up to 500Hz
cw & pulsed quick coupling 1 - 8 inputs USB 2.0 spectral profile monitoring linewidt

The optical unit and associated electronics are housed in a compact, thermal casing. The connection to a computer or notebook is realized via a high speed USB 2.0 port, which allows a high data read-out rate. The analyzing software displays all the interferometer information and is compatible with Microsoft Windows.

Standard features of the basic wavelength meters are:
Measurement of wavelength, frequency & co.

The measurement is displayed on the computer via the supplied user-friendly software. Installation and setup is straight forward. The displayed result may be switched between wavelength, frequency, wave number or -energy to suit the test requirements. The displayed interferometer pattern provides information regarding the spectral profile of pulsed or continuous wave laser sources.

Long-term measurement:
This application records all measurement results and displays it graphically along with calculating the mean, max. and min., as well as standard deviation. Many long-term windows can be open simultaneously to display all available information of up to 8 laser sources (multichannel option).

Record- and Replay Mode:
This operation mode records all interferometer data and allows for a subsequent play-back.

Average:
Two different arithmetic averaging techniques may be applied on 0 to 999 measurement points.

Data-Control:
An easy access API provides a fast interface to all functionalities for controlling the WLM and accessing its data. Source code for sample programs is included.

Standard options include:
